Standard: UL – Std. 758. Complies to CSA No. 22.2 210 and 127

Nominal Voltage: 600V

Test Voltage (Spark Test):

AWG 22 and 20: 5kV

AWG 18 to 10: 6kV

≥ AWG 8: 7.5kV

Temperature Range: Flexible -5°C to +150°C. Fixed installation -50°C to +150°C

Temperature at Conductor: Max. UL : +150°C

Bending Radius: Approx. 5 x cable ø
