Panel Mount Terminal Block

<p>CM series Terminal Blocks have a side wire entry configuration. These blocks are an excellent solution for extremely compact wiring applications. The Terminal Blocks are &quot;modular&quot; and can be stacked to form multipole assemblies. The stacked assemblies can be mounted on the panel surface using an End Plate at one end only. These Terminal Blocks are perfect solution for industries like Control Transformer, Elevators, Junction Boxes and applications with limited wiring space. CSCP2.5T &amp; CSCP2.5T2 Terminal Blocks have top wire entry. Jumpers can be easily inserted by using Spring Clamp Actuator tool SCA2.5. The CXCP2.5/4 Terminal Block has the same profile as the CSCP2.5T terminals and can be stacked together with them. The CXCP2.5/4 terminals can be mounted on standard DIN Rails. The terminals with &amp; IECEx approval can be used in potentially explosive atmosphere</p>

Electronic Components

<p>These are electronic series spring clamp double level Terminal Blocks with built in diodes and LED. The built in diode acts as a free wheeling diode which is connected across the inductive load such as relay coils, solenoid valves, contactor coils to eliminate or suppress sudden voltage spike which appears across the load when its supply voltage is removed. CXDL2.5(E)LD1 Terminal Block has a built in LED circuit for online indication. CX2.5/4(E)D1 is specially designed 4 wire spring clamp Terminal Block with a built in diode. This Terminal has a built in 1N4007 diode for reverse polarity protection and also allows uni directional flow of current.</p>
